Transmission Control Systems

List of all DTCs with the Malfunction Indictor Light (MIL) condition - 5 Spd. Automatic Transmission 01V

Note:
^ Dcy = Driving cycle, conditions for recognition of a Dcy.
^ Explanation of the Malfunction indicator Lamp (MIL).
^ The "MIL" column in the DTC table indicates the condition for which the Malfunction Indicator Lamp (MIL) would be switched on. If, for example, "2 Dcy" is indicated in the table, the MIL would light up after two driving cycles. If "Off" is indicated, the malfunction has no influence on the MIL. If "On" is indicated, the MIL will light up immediately after the malfunction occurs.
^ "Hydraulic control" column

00258P0753-00270P1828:

00293P0705-00638P0702:

00638P1767-17094P0710:

17095P0711-17136P0752:

17137P0753-18155P1747:

18156P1748-18232P1824:

18233P1825-65535:
