(E85) Z4 SMG 6-Speed Sequential Manual Gearbox (If Equipped)

(E85) Z4 SMG 6-Speed Sequential Manual Gearbox (if equipped)
The optional Sequential Manual Gearbox (H-SMG) is a further development of the (E85) Z4 GS6-37BZ 6-speed manual (H-gearbox). Compared to previous SMG technology, changes include:
^ Completely new transmission
^ Mounting positions of the hydraulic components and the sensors on the transmission housing.
In combination with the SMG option, the customer also obtains the Dynamic Driving Control function. This function provides a Sport effect on driving by influencing the Engine Management, Transmission (SMG and EGS) and Electronic Power Steering (EPS) control systems. This function is activated with the Sport button.





System Overview - Inputs/Outputs
