Home >> Chevrolet >> 1992 >> Lumina V6-191 3.1L >> Repair and Diagnosis >> Lighting and Horns >> Headlamp >> Testing and Inspection >> With Daytime Running Lamps >> Test C: Flash to Pass Test >> Table 2

Table 2

Test C: Daytime Running Lights (DRL) Module Test (Table 2):
