Backup Lamp: Service and Repair

REMOVAL PROCEDURE
1. Remove the tail lamp.
2. Disconnect the electrical connector (6).
3. Remove the circuit plate (1).
4. Remove the bulb (2) from the socket.

INSTALLATION PROCEDURE
1. Install the bulb (2) to the socket.
2. Install the circuit plate (1).
3. Connect the electrical connector (6).
4. Install the tail lamps.
