B0931

Diagnostic Chart:

CIRCUIT DESCRIPTION
The internal fault detection is handled by the driver information center (DIC).

CONDITIONS FOR RUNNING THE DTC
The DIC monitors the analog input value once every ignition cycle at power up.

CONDITIONS FOR SETTING THE DTC
The DIC does not detect the compass sensor. This may be due to a faulty sensor or a remote sensor (sunroof only) that is not connected to the DIC.

ACTION TAKEN WHEN THE DTC SETS
The DTC will be set and stored in non-volatile memory.

CONDITIONS FOR CLEARING THE DTC
^ The DTC will become history when the DIC no longer detects a failure.
^ The history DTC will clear after 100 fault free ignition cycles.
^ You may clear the DTC with a scan tool.
