ATF Press Tfp Man. Valve POS. Switch,Press CTRL Solenoid-PC SOL
ATF Press Tfp Man. Valve POS. Switch,Press CTRL Solenoid-PC SOL
Automatic Transmission Control Diagram (Automatic Transmission Fluid Pressure (TFP) Manual Valve Position Switch And Pressure Control Solenoid (PC SOL) Valve):
