Vanity Lamp: Service and Repair

VANITY MIRROR LAMP REPLACEMENT

REMOVAL PROCEDURE




1. Remove the lens from the vanity mirror using a small, flat bladed tool.
2. Use a small pair of needle nose pliers in order to remove bulb from the socket.

IMPORTANT: Use care when removing the bulb.

INSTALLATION PROCEDURE




1. Install the bulb to the socket.
2. Install the lens to the vanity mirror. Ensure the lens is retained.
