Ambient Air Temperature Sensor Replacement

Ambient Air Temperature Sensor Replacement

Removal Procedure





Caution: Refer to Battery Disconnect Caution Battery Disconnect Caution in Cautions and Notices.

1. Disconnect the negative battery cable.
2. Disconnect the ambient air temperature sensor electrical connector.
3. Remove the ambient air temperature sensor from the bracket.

Installation Procedure




1. Install the ambient air temperature sensor into its bracket.
2. Connect the electrical connector.
3. Connect the negative battery cable.
