Wiper Switch: Service and Repair

Rear Wiper/Washer Switch:

REMOVE OR DISCONNECT
1. Battery ground cable from the battery.
2. Screw (4) from the instrument panel.
3. Switch trim plate (3) from the instrument panel.
4. Connector (1) from the switch (2).
5. Switch (2) from the trim plate (3).


INSTALL OR DISCONNECT
1. Switch (2) to the trim plate (3).
2. Connector (1) to the switch (2).
3. Switch trim plate (3) to instrument panel.
4. Screw (4) to the instrument panel.
5. Battery ground cable to the battery.
