DTC 22
>>
Antilock Braking System (ABS) - Four Wheel Antilock Brakes (4WAL)
Antilock Braking System (ABS) - Four Wheel Antilock Brakes (4WAL)
Code 22 Missing Right Front Speed Signal (Set With Vehicle In Motion).:
