Plenum Side Vent Replacement

Plenum Side Vent:

REMOVE OR DISCONNECT

1. Front door sill plate.

2. Plenum side vent cover.

3. Bolts (175) (figure 17).

4. Vent (176).

INSTALL OR CONNECT

1. Vent (176).

- Tighten Bolts (175) to 2 Nm (18 in. lbs.).


2. Plenum side vent cover.

3. Front door sill plate.
