M/T - Revised Information

Number: 93-191-7B
Section: 7B
Date: MAY 1993
Corporate Bulletin No.: 367202
ASE No.: A3

Subject:
BORG-WARNER T5 MANUAL TRANSMISSION (REVISED INFORMATION)

Model and Year:
1993 S TRUCKS

SERVICE UPDATE

This information replaces the information found under BORG-WARNER T5 MANUAL TRANSMISSION in SECTION 7B3 of the 1993 Light Duty Truck Unit Repair Manual.

Beginning with the 1993 model year, the Borg-Warner T5 Manual Transmissions were built with needle bearings under the mainshaft gears.

Update your 1993 Light Duty Truck Unit Repair Manual with the pages, which are included.





Manual Update Page, 7B3-1





Manual Update Page, 7B3-2





Manual Update Page, 7B3-3





Manual Update Page, 7B3-4





Manual Update Page, 7B3-5





Manual Update Page, 7B3-6





Manual Update Page, 7B3-7





Manual Update Page, 7B3-8





Manual Update Page, 7B3-9





Manual Update Page, 7B3-10





Manual Update Page, 7B3-11





Manual Update Page, 7B3-12





Manual Update Page, 7B3-13





Manual Update Page, 7B3-14





Manual Update Page, 7B3-15





Manual Update Page, 7B3-16





Manual Update Page, 7B3-17





Manual Update Page, 7B3-18
