Auxiliary Power Outlet: Service and Repair

Description:

Remove or Disconnect
1. Instrument panel ashtray.
2. Using a small flat-bladed tool, depress retainers on instrument panel power accessory port.
3. Instrument panel power accessory port from ashtray.

Install or Connect
1. Instrument panel power accessory port to ashtray, pressing in until fully seated.
2. Instrument panel ashtray.
