Courtesy Lamp Replacement - Overhead Console

REMOVAL PROCEDURE
1. Unscrew the center of the lamp lens with a coin or a small screwdriver while pressing in on the lamp assembly.
2. Remove the lamp assembly.
3. Remove the bulb from the socket.

INSTALLATION PROCEDURE
1. Install the new lamp in the assembly.
2. Install the lamp assembly into the cavity.
3. Turn the lamp assembly in order to latch the assembly into place.
