C0229

Circuit Description
As the wheel spins, the wheel speed sensor produces an AC signal. The EBCM uses the frequency of the AC signal to calculate the wheel speed.

Conditions for Running the DTC
^ The ignition is ON.
^ All of the wheel speed sensor signals are above 32 km/h (20 mph) when the brake is applied or 19 km/h (12 mph) when the brake is released.

Conditions for Setting the DTC
Either of the following conditions will set DTC C0229:
^ A sudden loss of both of the front wheel speed sensor signals is detected for 15 milliseconds.
^ A sudden increase is detected in both of the front wheel speed sensor signals for 105 milliseconds.

Action Taken When the DTC Sets
^ The ABS, BRAKE and TRACTION OFF (if equipped with traction control) indicators are commanded on.
^ The ABS, DRP and Traction Control (if equipped) are disabled for the remainder of the ignition cycle.

Conditions for Clearing the DTC
^ The condition(s) responsible for setting the DTC are no longer present.
^ A scan tool is used in order to clear the DTC.

Important: After the DTC is cleared and the ignition is ON, the ABS indicator may remain on until the EBCM completes a power-up self-test. This test concludes when the vehicle reaches a speed of greater than 13 km/h (8 mph) and the wheel speeds are verified by the EBCM.

Diagnostic Aids
Operating the vehicle on extremely rough terrain can set DTC C0229 even if the system is functioning properly.
Thoroughly inspect connections or circuitry that may cause an intermittent malfunction. Refer to Testing for Intermittent and Poor Connections, Wiring Repairs and Connector Repairs under Diagrams, Diagnostic Aids.
