C0292

Circuit Description
The Powertrain Control Module (PCM) sends a "State of Health" message to the EBCM within 5.5 seconds after the modules are powered up. This message is sent via class 2 serial data communications.

Conditions for Running the DTC
The ignition is ON.

Conditions for Setting the DTC
The State of Health message is not received by the EBCM.

Action Taken When the DTC Sets
^ The TRACTION OFF indicator is commanded on.
^ The Traction Control is disabled for the remainder of the ignition cycle.

Conditions for Clearing the DTC
^ Repair the condition(s) responsible for setting the DTC.
^ Use a scan tool in order to clear the DTC.
