Chevy Truck
>>
2000
>>
C 2500 Suburban 2WD V8-6.0L VIN U
>>
Repair and Diagnosis
>>
Specifications
>>
Pressure, Vacuum and Temperature Specifications
>>
Discharge Air Temperature Sensor / Switch, HVAC
Discharge Air Temperature Sensor / Switch, HVAC
Sensor Resistance Table (Upper, Lower and Aux Air Temp - Ohms):
