Onstar (R) Microphone Replacement
REMOVAL PROCEDURE
1. Remove the overhead console.
2. Remove the microphone (2) from the overhead console (1).
3. Disconnect the microphone electrical connector (4).
INSTALLATION PROCEDURE
1. Mount the microphone (2) to the overhead console.
2. Connect the microphone electrical connector (4).
3. Reinstall the overhead console.
