Cabin Ventilation Grille: Service and Repair

Pressure Relief Valve Replacement

Removal Procedure

1. Open the roof stowage compartment lid.
2. Using a flat-bladed tool, remove the pressure relief valve from the opening.




3. Remove the pressure relief valve from the vehicle.



Installation Procedure





1. Align the pressure relief valve into the opening in the roof stowage compartment area.
2. Firmly press the pressure relief valve into the opening until it is fully seated.
3. Close the roof stowage lid.
