125. Exhaust Outlet Installation

Exhaust Outlet Installation





1. Install the exhaust outlet.
Caution: Refer to Fastener Caution (Fastener Caution) .
2. Install the exhaust outlet clamp and tighten to 15 Nm (11 lb ft) .




3. Install the exhaust outlet to right exhaust pipe bracket bolt and tighten to 34 Nm
(25 lb ft) .
4. Install the exhaust outlet heat shield.
5. Install the exhaust outlet heat shield bolts and tighten to 10 Nm (89 lb in) .
