P0706

SYMPTOM
P0706 - CHECK SHIFTER SIGNAL

WHEN MONITORED
Continuously with the ignition on.

SET CONDITION
3 occurrences in one ignition start of an invalid PRNDL DTC which lasts for more than 0.1 second.

POSSIBLE CAUSES
- INTERMITTENT WIRING AND CONNECTORS
- TRS T1 SENSE CIRCUIT OPEN
- TRS T3 SENSE CIRCUIT OPEN
- TRS T41 SENSE CIRCUIT OPEN
- TRS T42 SENSE CIRCUIT OPEN
- TRS, T1 SENSE CIRCUIT SHORT TO GROUND
- TRS, T3 SENSE CIRCUIT SHORT TO GROUND
- TRS T41 SENSE CIRCUIT SHORT TO GROUND
- TRS T42 SENSE CIRCUIT SHORT TO GROUND
- TRS T1 SENSE CIRCUIT SHORT TO VOLTAGE
- TRS T3 SENSE CIRCUIT SHORT TO VOLTAGE
- TRS, T41 SENSE CIRCUIT SHORT TO VOLTAGE
- TRS, T42 SENSE CIRCUIT SHORT TO VOLTAGE
- SHIFT LINKAGE OUT OF ADJUSTMENT.
- TCM - TRS T1 SENSE CIRCUIT
- TCM - TRS T3 SENSE CIRCUIT
- TCM - TRS T41 SENSE CIRCUIT
- TCM - TRS T42 SENSE CIRCUIT
- TRANSMISSION RANGE SENSOR
