P1695

Tests 1 - 3:

Test 4:

SYMPTOM
P1695-NO CCD/J1850 MESSAGE FROM BODY CONTROL MODULE

WHEN MONITORED
With the ignition ON. Battery voltage greater than 10.0 volts.

SET CONDITION
No BUS messages received from the BCM for 20 seconds.

POSSIBLE CAUSES
- Intermittent condition
- CCD Bus circuit(s) open
- Communicate with BCM
- PCM
