Courtesy Lamp: Service and Repair

REMOVAL




1. Disconnect and isolate the battery negative cable.
2. Remove the front door trim panel.




3. With the trim panel on bench, gently pull the door courtesy lamp (1) out of courtesy lamp unit.

INSTALLATION




1. Place the door courtesy lamp (1) into the courtesy lamp unit.




2. Install the front door trim panel.
3. Connect the battery negative cable.
