Capacitor-Ignition 2

Component ID: 67
Component : CAPACITOR-IGNITION 2

Connector:
Name : CAPACITOR-IGNITION 2
Color : BLACK
# of pins : 1
Qualifier : (2.7L/5.7L)




Pin Circuit Description
1 F343 16BR/YL FUSED ASD RELAY OUTPUT

Component Location - 17
