Temperature Gauge: Testing and Inspection

Temperature Gauge Inoperative, Other Gauges OK

Test Description
The numbers below refer to steps on the diagnostic table.
1. Begin the diagnostic table at Step 1 if the problem is that the temperature gauge always indicates full. Begin the diagnostic table at Step 7 if the problem is that the temperature gauge always indicates empty.
