MAP,IAT,EGR,A/C Press./TP/ECT Fuel Press. Sensor&Fuel Gauge CKT
MAP,IAT,EGR,A/C Press./TP/ECT Fuel Press. Sensor&Fuel Gauge CKT
Connector Identification Symbol & Pin Number Position:
Splice Pack - S210 (Blue):
