C123A

C123A-ESP SYSTEM SENSORS CALIBRATION

For a complete wiring diagram Refer to Diagram/Electrical. Electrical Diagrams

- When Monitored:

Once per ignition cycle.

- Set Condition:

If the calculated checksum does not match the stored checksum.





Diagnostic Test

1. INITIALIZE ANTI-LOCK BRAKES MODULE

Initialize ECU refer to ABS VERIFICATION TEST - VER 1. Verification Tests

Does this DTC reset?

Yes

- Replace the Anti-Lock Brake Module.
- Perform ABS VERIFICATION TEST - VER 1. Verification Tests

No

- Test complete.
