B2287

B2287-SATELLITE VIDEO RECEIVER INTERNAL

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
With the ignition on.

- Set Condition:
The Satellite Video Receiver detects an internal failure.





REPLACE THE SATELLITE VIDEO RECEIVER
1. When this DTC is active, replace the Satellite Video Receiver.

Repair

- Replace the Satellite Video Receiver. Satellite Video Module - Removal.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
