B25A3

B25A3-00-FRONT LEFT DOOR HANDLE SENSOR





For a complete wiring diagram, refer to the Wiring Information.

NOTE: Before proceeding, check the handle for any foreign material, or binding, that could cause a sticking situation to the handle or switch.

- When Monitored:
During a Passive Entry Event.

- Set Condition:
If the hall sensor in the handle stays active for longer than 120 seconds, this code will set.





1. TEST FOR INTERMITTENT CONDITION

NOTE: If there are any other PEM DTCs, perform the diagnostic procedure for them before proceeding.

1. Turn the ignition on.
2. Using the scan tool, record and erase the DTCs.
3. Open the Left Front window.
4. Turn the ignition off and close all doors.
5. Have the FOBIK outside the car and within 6 feet from the handle.
6. Lock and Unlock the Left Front Door by the outside handle four times.
7. Open the Left Front Door by pulling the handle.
8. Turn the ignition on.
9. Using the scan tool, read the Active DTCs.

Does the scan tool display: B25A3-00-FRONT LEFT DOOR HANDLE SENSOR as active?

Yes

- Go To 3

No

- Go To 2

2. DOOR HANDLE

In the previous step, did the Door Handle lock and unlock the door as it should?

Yes

- Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Go To 3

3. DOOR HANDLE OR PEM
1. Go to the Right Front Door.
2. Open the Right Front window.
3. Turn the ignition off and close all doors.
4. Have the FOBIK outside the car and within six (6) feet of the handle.
5. Lock and Unlock the Right Front Door by the outside handle four times.
6. Using the handle lock switch, lock the doors.
7. Open the Right Front Door by pulling the handle.

Did the Right Door Handle lock and unlock the door as it should?

Yes

- Replace the Left Front Door Handle. Front Exterior Handle - Removal.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Replace the PEM Module. Passive Entry Module - Removal.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
