Automatic Transmission/Transaxle: Application and ID

Model: W4A33-1-FNQ

Type: Electronically controlled 4-speed full-automatic.

Torque Converter:
Type: 3-element with torque converter clutch
Engine stall speed rpm: 3,300-3,800

Gear Ratio:
1st: 2.551
2nd: 1.488
3rd: 1.000
4th: 0.685
Reverse: 2.176

Reduction Ratio:
Final gear ratio: 4.361
Transfer: 1.074

Speedometer Gear Ratio (driven/drive): 28/36





Function Element Table
