Drive/Propeller Shafts, Bearings and Joints

Part 1 Of 2:

Part 2 Of 2:

NOTE: Use Ford Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A for complete refill of Dana limited slip rear axles. Add 0.2 liter (8 oz) for complete refill.

Note: No Data axles for E250, E350 or E450 have synthetic lubricant as factory fill. If any Econoline vehicle will be towing a trailer frequently, particularly in hot or hilly area, it is recommended that the axle be filled with 75W-140 synthetic lubricant or equivalent meeting Ford specification WSL-M2C192-A.
