Engine - Stall After Cold Start and Transaxle Engagement

Article No.
99-12-3

06/14/99

STALL - AFTER COLD START AND TRANSAXLE
ENGAGEMENT - VEHICLES BUILT THROUGH
2/15/1999 WITH 2.OL ZETEC ENGINE AND ATX
TRANSAXLE

FORD:
1998-1999 ESCORT ZX2

CALIBRATION
8-04E, 8-04R, 9EOA-AK 9EOA-BK

WARNING
THIS MODIFICATION IS AUTHORIZED ONLY FOR THE LISTED ENGINE(S). PERFORMING THIS MODIFICATION ON OTHER ENGINE CALIBRATIONS IS UNAUTHORIZED AND COULD CREATE LIABILITY UNDER APPLICABLE FEDERAL OR LOCAL LAWS.

ISSUE
Some vehicles may exhibit a stall after a cold engine start when the transmission is initially shifted into gear. This issue may be caused by using a summer blend fuel in colder ambient temperatures of -1°C to 15°C (30° F to 60°F).





ACTION
Reprogram the Powertrain Control Module (PCM) using the Service Bay Diagnostic System (SBDS) or New Generation Star (NGS) Tester. Refer to the following PCM Reprogramming Information Chart to identify the appropriate calibration.





Obtain an Authorized Modifications Decal (FPS 8262 - obtainable through DOES II, 25Ipkg) and list the date, dealer number, and summary of modifications performed. Select a prominent place adjacent to the Vehicle Emission Control Information Decal suitable for installing the Authorized Modifications Decal. Clean the area, install the decal, and cover it with a clear plastic decal shield.

OTHER APPLICABLE ARTICLES: NONE

WARRANTY STATUS: Eligible Under The Provisions Of Bumper To Bumper Warranty Coverage

OPERATION DESCRIPTION TIME

991203A Reprogram Powertrain 0.4 Hr.
Control Module (PCM)

DEALER CODING
CONDITION
BASIC PART NO. CODE
RECAL 42

OASIS CODES: 602300, 607000, 607400, 607500, 608400
