Cowl: Service and Repair

REMOVAL
1. Raise and support the hood.
2. Remove the windshield wiper pivot arms.







3. Remove the cowl top vent grille.
^ Remove the (A) center cowl top vent grille retainers and screws, and the (B) outer cowl top vent grille retainers, screws, and washers. Remove the cowl top vent grille.

INSTALLATION







1. To install, reverse the removal procedure.
