Home
>>
Ford
>>
2006
>>
Focus L4-2.0L VIN N
>>
Repair and Diagnosis
>>
Specifications
>>
Mechanical Specifications
>>
Engine
>>
Oil Pan, Engine
Oil Pan, Engine
Oil Pan
-to-Bellhousing Bolts
48 Nm (35 ft. lbs.)
Other
Oil Pan
Bolts
25 Nm (18 ft. lbs.)
