Freightliner Truck
>>
2009
>>
Sprinter 2500 V6-3.0L DSL Turbo
>>
Repair and Diagnosis
>>
Diagrams
>>
Connector Views
>>
Fuel Pressure Sensor/Switch
Fuel Pressure Sensor/Switch
Connector (DIESEL) - (OM642) 2 WAY
SENSOR-FUEL PRESSURE (DIESEL) - (OM642) 2 WAY
