A/C, Heater, Temperature and Fan Control Knobs - Loose
99-088November 9, 1999
Applies To: 1998-00 Accord - All except EX V6
Loose or Broken Temperature and Fan Control Knobs
SYMPTOM
The temperature or fan control knob feels loose.
PROBABLE CAUSE
Residual grease from the switches gets on the control knobs, the grease deteriorates the plastic, and the knobs crack or break.
CORRECTIVE ACTION
Clean the switch shafts with denatured alcohol or other non-petroleum-based cleaner, and install the new control knobs.
PARTS INFORMATION
Temperature and Fan Knob Set:
P/N 79581-S84-999, H/C 6358790
WARRANTY CLAIM INFORMATION
In warranty: The normal warranty applies.
Operation number: 610108
Flat rate time: 0.2 hour
Failed part: P/N 79581-S84-A01
H/C 5447255
Defect code: 018
Contention code: A02
Template ID: 99-088A
Skill level: Maintenance Technician
Out of warranty: Any repair performed after warranty expiration may be eligible for goodwill consideration by the District Service Manager or your Zone Office. You must request consideration, and get a decision, before starting work.
REPAIR PROCEDURE
1. Use a pair of pliers to remove the old or broken temperature and fan control knobs.
NOTICE: To avoid damaging the center panel, do not pry off the knobs.
2. Clean both switch shafts with denatured alcohol; make sure you remove all grease from the shafts.
3. Install the new control knobs.
