Muffler Paint Peeling

99-063

December 21 1999

Applies To:
1998-00 Accord V6 - All

Muffler Paint Peeling

PROBLEM
The black paint is peeling off the muffler(s). This paint is applied only for improved appearance; it is not for corrosion protection.

CORRECTIVE ACTION
Repaint the visible areas of the muffler and tailpipe.

REQUIRED MATERIALS
Premium De'cor High Heat Spray Paint, # PD-1552 Flat Black
or
Dupli-Color High Heat Spray Paint, # DH1602 Black
or
Krylon BBQ & Stove Spray Paint, # 1618 BBQ Black

WARRANTY CLAIM INFORMATION

In warranty: The normal warranty applies.

Operation number: 311400
Flat rate time: 0.4 hour
Failed part P/N 18030-584-A01 H/C 5787098
Defect code: Z86
Contention code: A01
Template ID: 99-063A
Skill level: Maintenance Technician

Out of warranty: Any repair performed after warranty expiration may be eligible for goodwill consideration by the District Service Manager or your Zone Office. You must request consideration, and get a decision, before starting work.

REPAIR PROCEDURE

1. Use 220 grit sandpaper to remove the peeling paint and to rough up the surface.

2. Use a solution of dishwashing detergent and water to thoroughly clean the area to be painted.

3. Rinse the surface completely. Make sure you remove all the detergent residue.

4. Allow the surface to dry completely.

5. Clean the surface to be painted with a shop towel saturated with isopropyl alcohol. Allow the alcohol to evaporate completely before continuing.

6. Repaint the cleaned area with one of the spray paints listed under REQUIRED MATERIALS.
