Active Noise Control Microphone Removal/Installation

Active Noise Control Microphone Removal/Installation

Front-2006 model
1. Remove the headliner.




2. Disconnect the connector (A), then remove the screws and the active noise control microphone (B).
3. Remove the cap (C) from the base (D).
4. Install the microphone in the reverse order of removal.

Rear
1. Remove the rear shelf.




2. Disconnect connector (A), then remove the screws and the active noise control microphone (B).
3. Install in the reverse order of removal.
