Rear Power Window Motor Test

Rear Power Window Motor Test

1. Remove the rear power window switch.

2. Test the motor in each direction by connecting battery power and ground to the rear power window switch 14P connector (A) according to the table.










3. If the motor does not run or fails to run smoothly, go to step 4.

4. Remove the door panel.

5. Disconnect the 2P connector (A) from the rear power window motor (B).






6. Check for continuity between the rear power window switch 14P connector terminals and rear power window motor 2P connector terminals as shown. There should be continuity.









7. If the wire harness is OK, the rear power window motor is faulty; replace the rear door regulator Service and Repair.
