Washer Fluid Level Switch Test

Washer Fluid Level Switch Test

Canada models

1. Remove the right front inner fender.

2. Disconnect the 2P connector (A) from the washer fluid level switch (B).





3. Remove the washer fluid level switch from the washer reservoir.

NOTE: Fluid may flow out of the opening.

4. Check for continuity between the terminals in each switch position according to the table.





5. If the continuity is not as specified, replace the switch Service and Repair.
