5. 2-4 Servo Cover and Assembly Removal

2-4 SERVO COVER AND ASSEMBLY REMOVAL

TOOLS REQUIRED
J 29714-A Servo Cover Compressor




1. Install the J 29714-A.

IMPORTANT: If cover does not move inwards with tool, use a block of wood or suitable material and lightly tap on cover using a hammer to free up cover in bore.




2. Tighten the bolt using J29714-A to compress the servo cover.




3. Remove the servo cover retaining ring and the J 29714-A.




4. Remove the servo cover and O-ring seal. If the servo cover seems to be hung up on the seal, cut and remove the O-ring seal before removing the cover.
5. Remove the 2-4 servo assembly.
