Initial Inspection and Diagnostic Overview

CHECK CLUTCH PEDAL
Check that pedal height, pedal freeplay and clutch pedal clevis pin play are correct.




CHECK STARTER RELAY
Remove the starter relay and check continuity between the terminals. If the continuity is not as specified, replace the relay.




CHECK IGNITION LOCK SWITCH
Check for continuity between terminals.
