Scantool Diagnostics

Electronic Control Suspension
C1702 Variant Coding Error - Scantool Diagnostics

Variant coding

1. Connect scantool to Data Link Connector (DLC).
2. IG "ON"
3. Using scantool, Perform Variant coding program.
4. IG "OFF" and then, IG "ON", Perform Height sensor's Calibration program with scantool. (Fig.1)
5. IG "OFF" and then, IG "ON, Go to "Component Inspection" procedure.
