Power Trunk / Liftgate Control Module

SD952-17 Power Trunk Module (PTM) (1):

SD952-18 Power Trunk Module (PTM) (2):

SD952-19 Power Trunk Module (PTM) (3):

Diagrams: Other diagrams referred to by SD number (i.e SD130-4, etc.)
within these diagrams can be found at Diagrams by Number. Diagram By Number

Locations: Location photographs (references to PHOTOS) referred to within
these diagrams can be found via the photo number at the vehicle level under
Locations by Photo Number. Locations By Photo Number
