Exhaust Manifold

Exhaust Manifold

Install the LH/RH exhaust manifolds (A).

Tightening torque 49.0 - 53.9N.m (5.0 - 5.5kgf.m, 36.2 - 39.8lb-ft)

[RH]






NOTE: Use an universal joint wrench (B) to loosen the upper and lower nuts on the RH exhaust manifold.

[LH]






NOTE: Use an universal joint wrench (B) to loosen the upper nuts on the LH exhaust manifold. To loosen the lower nuts on the LH exhaust manifold, use an extension bar (C) and an universal joint (D) after removing the front wheel and side cover on LH side.






NOTE: Tighten the exhaust manifold mounting nuts as following method.

[LH]






[RH]
