Parking Brake System: Adjustments

Fig. 7 Parking brake adjuster:

1. Remove adjuster hole plug and turn down adjuster wheel with a screwdriver until shoe touches brake drum.
2. Return adjuster wheel 5-6 latches, Fig. 7.
3. Install adjuster hole plug and ensure there is no drag between shoes and drum when rotating disc rotor.
