Timing Components: Specifications

Install crankshaft pulley to crankshaft.
Lubricate thread and seat surface of the bolt with new engine oil.

a. Tighten to 39 to 49 Nm (4.0 to 5.0 kg-m, 29 to 36 ft. lbs.).
b. Put a paint mark on the crankshaft pulley.
c. Again tighten by turning 60° to 66°, about the angle from one hexagon bolt head corner to another.
