Automatic Transmission/Transaxle: Application and ID
AUTOMATIC TRANSMISSION/TRANSAXLESpecifications and Adjustment
CLUTCHES AND BRAKES
Reverse clutch
High clutch
Forward clutch
Overrun clutch
Low & reverse clutch
TOTAL END PLAY
REVERSE CLUTCH DRUM END PLAY
