Telescopic Motor

TELESCOPIC MOTOR

Description
- The telescopic motor is installed on the steering column assembly.
- The telescopic motor is activated with the automatic drive positioner control unit.
- Telescopic operates forward/backward by changing the rotation direction of telescopic motor.

Component Function Check

Step 1:






Diagnosis Procedure

Step 1-2:




Step 2 (Continued)-3:
