Brakes - Electronic Park Brake Calibration Procedure

S-TYPE

S206-04

DATE: 08/05

MODEL:
2003 MY-ON
S-TYPE

VIN:
M44998-ON

Electronic Park Brake (EPB) - Re-Calibration Procedure

Issue:

On some 2003 MY-on S-TYPE vehicles, a customer may report a concern of premature parking brake pad wear or the brakes binding. This condition can result if the electronic park brake (EPB) system is not re-calibrated after the removal of the rear brake calipers to replace the brake pads.

Action:

Should a customer express concern regarding the above, refer to the calibration procedure detailed in this bulletin.

1. Reset the EPB module:

a. Switch off the ignition.

b. Disconnect the battery for 30 seconds. For additional information, refer to S-TYPE Workshop Manual Section 414-01.

c. Reconnect the battery.

2. Start the engine.

3. Firmly apply and release the footbrake five times.

4. Confirm that the message "NOT CALIBRATED" or "APPLY FOOT AND PARK BRAKE" is displayed on the instrument cluster message center. This indicates that the parking brake is in calibration mode.

5. Lightly press the footbrake pedal.

6. Apply the parking brake by using the EPB switch.

7. Release the parking brake.

8. Release the footbrake.

9. Confirm that the brake warning lamp is no longer illuminated on the instrument pack and that the "NOT CALIBRATED" message is no longer displayed in the message center.

10. Apply and release the EPB five times to ensure no error is present.

Global Technical Reference (GTR) Workshop Manual Information:

Internet access: http://www.jaguartechinfo.com





Parts Information

Warranty Information:





Warranty claims should be submitted quoting the information found in the table.

This will result in payment of the stated time and, where applicable parts/miscellaneous expense codes as listed.
